Technical Specifications: Comprehensive data for industrial diamond cutting segments and blades performance.
| EAN-CODE |
Dimension (mm) |
Package (pcs) |
G.W. (kg) |
N.W (kg) |
Meas (cm) |
Cut Meters |
| PED105207 |
105×20×7 |
200 |
19 |
17 |
52×30×16 |
100-145M |
| PED110207 |
110×20×7 |
200 |
20 |
18 |
52×30×16 |
105-150M |
| PED115227 |
115×22.23×7 |
200 |
22 |
20 |
52×30×16 |
110-160M |
| PED125227 |
125×22.23×7 |
200 |
28 |
27 |
35×33×38 |
120-175M |
| PED150227 |
150×22.23×7 |
100 |
24 |
23 |
30×34×18 |
180-260M |
| PED180227 |
180×22.23×7 |
50 |
18 |
17 |
20×35×21 |
250-350M |
| PED200227 |
200×22.23×7 |
50 |
23 |
22 |
22×23×18 |
270-370M |
| PED230227 |
230×22.23×7 |
30 |
21 |
20 |
26×27×21 |
370-470M |
| PED250257 |
250×25.4×7 |
30 |
25 |
24 |
27×27×21 |
400-500M |
| PED300257 |
300×25.4×7 |
20 |
22 |
21 |
32×32×16 |
500-600M |
| PED350257 |
350×25.4×7 |
10 |
18 |
17 |
37×37×8 |
600-700M |
💡 Frequently Asked Questions
1. What do the "Cut Meters" values represent in the table?
The "Cut Meters" column indicates the estimated total cutting distance the blade can achieve under standard operating conditions. Higher values signify longer blade life and higher diamond concentration or segment quality.
2. Are these diamond blades suitable for wet or dry cutting?
These blades are designed to handle both wet and dry applications. However, wet cutting is generally recommended for larger diameters (above 230mm) to ensure cooling and maximize the tool's lifespan.
3. How do I choose the correct bore size (Dimension mm)?
The middle value in the dimension (e.g., 22.23 in 115×22.23×7) represents the bore diameter. Ensure this matches your machine's spindle size. Standard sizes include 20mm, 22.23mm, and 25.4mm.
4. What materials can be cut with the PED series?
The PED series is optimized for cutting a variety of hard materials, including granite, marble, concrete, and ceramic tiles, depending on the specific segment configuration shown in the technical specifications.
5. Why is the Gross Weight (G.W.) significantly higher than the Net Weight (N.W.)?
The difference accounts for the professional-grade export packaging designed to protect the diamond segments from impact and moisture during long-distance transit.
6. Can I use a 350mm blade on a hand-held angle grinder?
No, 350mm blades are typically intended for stationary cutting machines or walk-behind saws. Always verify your equipment's maximum allowable blade diameter and RPM rating before installation.
